and after dismiss this notifier Design Checking for Critical Speed and Elastic Limit Option is Open.ģ. In this Calculator you have to give input as Total Power of Agitation in HP, Agitator Speed in RPM and Shaft Material Permissible Shear Stress in N/mm2 and then click on Calculate Button to Get Shaft Diameter then Popup Notification is highlighted with Desired Shaft Diameter in mm.
Agitator Shaft Diameter Calculator : This Tool is used for Calculating Shaft Diameter for Transmitting Desired Power Requirement for Agitation Process. In this Calculator Gland Loss are assumed as 10% and Transmission loss as 20% of the Power of Agitation.Ģ. in Output Page you will get result as Power of Agitation in HP, Gland loss in HP and Transmission Loss in HP and Total Power Requirement for Agitator in HP. and then select Agitator Blade Types from the list and Press Calculate Button to Generate Result Output. In this tool you have to enter input as Agitator Sweep Diameter in mm, Agitator Speed in RPM, Content Material Density in Kg/m3 and No. Agitator Power Calculator : This Calculator is useful for Agitation Power Requirement Calculation. Pitched Blades with 2 Nos, 4 Nos and 6 Nos Leafs to Each Bladeġ. Straight Blades with 2 Nos, 4 Nos and 6 Nos Leafs to Each BladeĢ. In This App Following Blades Options Are Available :ġ. In this App Following Calculators are Available : This App is Useful for those who are working in Process Equipment Manufacturing and Agitation and Mixing Equipment Manufacturing Industry.Ģ. In this App Agitator Power Requirement Calculations for all types of Blades of Agitation, Agitator Shaft Diameter Calculation, Agitator Shaft Design Checking for Critical Speed and Elastic Limits for Design Safety, Stuffing Box Design Calculations re available in one simple Tool so that Designer can do handy Calculation on any time anywhere. This App Used for Agitator Design Calculations or Mixer Design Calculations.
